EXBE-2
Bass Restoration Processor
Features
- Factory Radio Speaker Hi-level inputs
- Balanced Inputs RCA Low-Level inputs
- Integrated Line Driver output
- Variable Subsonic Filter
- Variable Gain Adjustment with Clip LED indicator
- Auto Turn-On Audio Signal Detect
- +12V Remote Output (for factory radio integration)
- Selectable Ground Isolation
- Removable Power/Speaker Terminals
- Audiophile Tiffany RCA inputs
- Includes Remote Level Control with Effect Defeat
Specifications
| Input Sensitivity | |
|---|---|
| Hi-Level | 2-20Vs - 4-40V (internally selectable) |
| RCA | 4KHz - 22.5KHz0.5-5V-1-10V (internally selectable) |
| Maximum Hi-Level Input Voltage | 40Vrms |
| Frequency Response | 15Hz to > 25kHz |
| THD+N (SPK/RCA) | <0.05% / <0.1% |
| Maximum Output Voltage | -10Vrms |
| Bass Restoration | |
| Effect Gain | 0 - 18dB |
| Width | Nar-Wide |
| Freq | 30 - 80Hz |
| Variable Subsonic Filter | 15Hz - 50Hz |
| +12V Remote Output | 500mA |
| Chassis Dimensions | 1.1" x 3.5" x 5.2" (29 x 90x 133mm) |
Description
Pump up the bass and feel the Euphoria!
Introducing the EXBE-2 Bass Restoration Processor by Euphoria, the ultimate game-changer for bass enthusiasts. This innovative device is engineered to breathe new life into your factory radio speakers with high-level inputs and balanced RCA low-level inputs. With a frequency response from 15Hz to over 25kHz, you’ll experience bass like never before. The EXBE-2 features an integrated line driver output, variable subsonic filter, and variable gain adjustment with a clip LED indicator for precision tuning. It also includes a remote level control with effect defeat, making it versatile for any setup. Plus, with +12V remote output for factory radio integration and selectable ground isolation, installation is a breeze. Get ready to elevate your audio experience and immerse yourself in the Euphoria of unparalleled bass!
