EA1.1800
Amplificador mono Clase D
Features
-
High-efficiency full-range Class D technology
-
Audiophile-grade Tiffany RCA connectors
-
ACT adaptive low-pass filter
-
ACT adaptive subsonic filter
-
SESI operating status indicator
-
Bass optimization EQ
-
Direct Connect speaker outputs
-
Large-gauge power wire inputs
-
APC audio circuit protection
-
Remote gain control included
Specifications
1 × 1800 Watts @ 1 ohm
1 × 900 Watts @ 2 ohms
1 × 450 Watts @ 4 ohms
Low-Pass Filter: 40 Hz – 250 Hz
Subsonic Filter: 10 Hz – 50 Hz
Bass EQ @ 45 Hz: 0 dB – 12 dB
Operating Voltage: 9–16 Volts
Frequency Response: 20 Hz – 250 kHz
Signal-to-Noise Ratio: < 82 dB
Damping Factor @ 100 Hz, 4 volts/4 ohms: < 400
Low-Level Input: 450 mV – 6.5 V
Description
For those who demand premium sound, the Euphoria EA1.1800 is a monoblock subwoofer amplifier engineered to deliver powerful, dynamic, and accurate bass.
With an output of 1800 watts at 1 ohm and compatibility with 1-, 2-, or 4-ohm loads, it offers flexibility for a wide range of audio system configurations. Its high-efficiency Class D design is well suited for modern electrical systems, while its adaptive filters allow precise subwoofer tuning for optimized performance.
It includes a dash-mounted remote level control, high-precision metal potentiometers, a four-layer PCB for cleaner signal transfer, and a compact design that simplifies installation in limited spaces.
